ENGINEERED DRAINAGE & HYDRAULICS

• We maintain a strict 2% minimum slope across the entire surface profile. This ensures immediate hydraulic runoff, preventing water from pooling in the joints and saturating the sub-base, which is the leading cause of shifting and stone "heaving."

> Pro Tip: Sub-surface water is the primary enemy of interlock. If a contractor isn't using a laser level to set the grades and proper aggregate for drainage, the surface will develop depressions that turn into ice patches and uneven, sunken stones within two winters.

​​

MAXIMUM LOAD DISTRIBUTION

• We utilize high-density, 80mm paving units with a minimum compressive strength of 55 MPa (8,000 PSI). This exceeds the strength of standard concrete, providing a modular surface that can support high-capacity vehicle loads without the risk of surface cracking or structural failure.

> Pro Tip: While 60mm stones are common for walkways, they often lack the mass required for driveways. At KCDL, we exclusively specify 80mm high-density units for vehicular areas to ensure the stones don't tilt or rotate under the weight of heavy SUVs and trucks.

​

NON-YIELDING FOUNDATION

• We replace unstable subgrade with 12"–18" of Granular A base material, mechanically compacted in 4-inch lifts to 98% Standard Proctor Density. This creates a rigid, non-yielding foundation that distributes weight evenly and prevents the deep-seated "rutting" common in amateur installations.

> Pro Tip: Using "stone screenings" as a base is a major failure point in Ontario. Screenings hold water and turn into mush during the thaw; a clean, crushed Granular A base is the only engineering solution to ensure your driveway stays perfectly level for decades.

GEOTECHNICAL SOIL STABILIZATION

• Every project includes a layer of industrial-grade woven geotextile fabric between the native soil and our stone base. This acts as a structural separator, preventing the heavy stone base from sinking into the soft clay sub-soil over time.

> Pro Tip: In the GTA, high-plasticity clay soils often absorb the gravel base under the weight of vehicles, a process known as "base thinning." By installing a geotextile interface, we maintain the design thickness of your foundation and prevent the intermixing of soil fines, ensuring the driveway remains structurally sound for its entire service life.

​

POLYMER-LOCKED JOINT INTEGRITY

• We utilize high-performance polymeric jointing sand that chemically bonds when activated with water. This creates a flexible yet durable seal that prevents weed growth, resists ant infestations, and stops water from washing away the bedding sand underneath the stones.

> Pro Tip: Standard joint sand washes away in the first rain, leaving the edges of your stones unsupported. High-quality polymeric sand acts like a "flexible grout," locking the entire surface into a single, unified slab while still allowing for natural thermal expansion.
